DFLib::Proj::Report Class Reference

DF report in user-specified coordinates. More...

#include <DF_Proj_Report.hpp>

Inheritance diagram for DFLib::Proj::Report:

Collaboration diagram for DFLib::Proj::Report:

Public Member Functions
	Report (const std::vector< double > &theLocationUser, const double &bearing, const double &std_dev, const std::string &theName, const std::vector< std::string > &projArgs)
	DF report constructor for user-specified coordinate system.
	Report (const Report &right)
	Copy constructor.
Report &	operator= (const Report &rhs)
	assignment operator
virtual	~Report ()
	virtual destructor because base classes need one
virtual const std::vector< double > &	getReceiverLocation ()
	return receiver location in double vector of XY coords
virtual Point	getReceiverPoint () const
	return a copy (yes, a COPY) of the receiver point object
virtual double	getReportBearingRadians () const
	return reported bearing to target
virtual double	getBearing () const
virtual double	getBearingStandardDeviationRadians () const
virtual double	getSigma () const
virtual void	setReceiverLocationUser (const std::vector< double > &theLocation)
virtual void	setReceiverLocationMercator (const std::vector< double > &theLocation)
virtual void	setBearing (double Bearing)
	set bearing in degrees
virtual void	setSigma (double Sigma)
	set standard deviation in degrees
virtual void	setUserProj (const std::vector< std::string > &projArgs)
	allow us to change the projection of the user coordinates
Public Member Functions inherited from DFLib::Abstract::Report
virtual	~Report ()
	virtual destructor because base classes need one
	Report (std::string n, bool v)
	constructor for base Report class
	Report (const Report &right)
	copy constructor for base Report class
virtual const std::vector< double > &	getReceiverLocation ()=0
	return receiver location in double vector of XY coords
virtual double	getReportBearingRadians () const =0
	return reported bearing to target
virtual double	getBearingStandardDeviationRadians () const =0
virtual const std::string &	getReportName () const
	Return the name of this report.
virtual void	setReportName (const std::string &theName)
	set the name of this report
virtual void	setValid ()
	Set this report as valid.
virtual void	setInvalid ()
	Set this report as invalid.
virtual void	toggleValidity ()
virtual bool	isValid () const
	check this report's validity
void	computeFixCut (DFLib::Abstract::Report *Report2, Point &returnPoint, double &cutAngle, FixStatus &fs)
	compute point at which the line from this report intersects that from another
double	computeBearingToPoint (std::vector< double > &aPoint)
	compute bearing from this reporting location to some other point
double	computeDistanceToPoint (std::vector< double > &aPoint)
	compute distance from this reporting location to some other point.

Private Attributes
Point *	receiverLocation
double	bearing
double	sigma

Detailed Description

DF report in user-specified coordinates.

Constructor & Destructor Documentation

Report() [1/2]

DFLib::Proj::Report::Report	(	const std::vector< double > &	theLocation,
		const double &	Bearing,
		const double &	std_dev,
		const std::string &	theName,
		const std::vector< std::string > &	projArgs
	)

DF report constructor for user-specified coordinate system.

Parameters

theLocation	position vector in lat/lon of this report.
Bearing	bearing IN DEGREES
std_dev	standard deviation in degrees
projArgs	a vector of strings to pass to proj_create_argv in order to define the user coordinate system.

Report() [2/2]

DFLib::Proj::Report::Report

(

const Report &

right

)

Copy constructor.

~Report()

DFLib::Proj::Report::~Report ( )

virtual

virtual destructor because base classes need one

Reimplemented from DFLib::Abstract::Report.

Member Function Documentation

getBearing()

double DFLib::Proj::Report::getBearing ( ) const

inlinevirtual

getBearingStandardDeviationRadians()

double DFLib::Proj::Report::getBearingStandardDeviationRadians ( ) const

inlinevirtual

Implements DFLib::Abstract::Report.

Here is the caller graph for this function:

getReceiverLocation()

const std::vector< double > & DFLib::Proj::Report::getReceiverLocation ( )

inlinevirtual

return receiver location in double vector of XY coords

Implements DFLib::Abstract::Report.

getReceiverPoint()

Point DFLib::Proj::Report::getReceiverPoint ( ) const

virtual

return a copy (yes, a COPY) of the receiver point object

Here is the caller graph for this function:

getReportBearingRadians()

double DFLib::Proj::Report::getReportBearingRadians ( ) const

inlinevirtual

return reported bearing to target

It is essential that getReportBearingRadians always return the bearing in the correct range .

Returns

bearing in radians, always in the range .

Implements DFLib::Abstract::Report.

Here is the caller graph for this function:

getSigma()

double DFLib::Proj::Report::getSigma ( ) const

inlinevirtual

operator=()

Report & DFLib::Proj::Report::operator=

(

const Report &

rhs

)

assignment operator

Here is the call graph for this function:

setBearing()

void DFLib::Proj::Report::setBearing ( double  Bearing )

inlinevirtual

set bearing in degrees

Here is the caller graph for this function:

setReceiverLocationMercator()

void DFLib::Proj::Report::setReceiverLocationMercator ( const std::vector< double > &  theLocation )

inlinevirtual

setReceiverLocationUser()

void DFLib::Proj::Report::setReceiverLocationUser ( const std::vector< double > &  theLocation )

inlinevirtual

setSigma()

void DFLib::Proj::Report::setSigma ( double  Sigma )

inlinevirtual

set standard deviation in degrees

setUserProj()

void DFLib::Proj::Report::setUserProj ( const std::vector< std::string > &  projArgs )

inlinevirtual

allow us to change the projection of the user coordinates

Member Data Documentation

bearing

double DFLib::Proj::Report::bearing

private

receiverLocation

Point* DFLib::Proj::Report::receiverLocation

private

sigma

double DFLib::Proj::Report::sigma

private

---

The documentation for this class was generated from the following files:

• /users/russo/DFLIB_Git/DFLib/DF_Proj_Report.hpp
• /users/russo/DFLIB_Git/DFLib/DF_Proj_Report.cpp
